NCP Dynamic Net Guard
Centrally managed Personal Firewall

NCP Net Guard

NCP Products
NCP Managed Dynamic Net Guard
NCP Dynamic Net Guard Client (Windows 32/64 Bit), 1 to 99 users
*Price per user. Quantity must be 1 or greater
#BNDPF1
Our Price: $126.50
NCP Dynamic Net Guard Client (Windows 32/64 Bit), 100 to 249 users
*Price per user. Quantity must be 100 or greater
#BNDPF2
Our Price: $109.25
NCP Dynamic Net Guard Client (Windows 32/64 Bit), 250 to 499 users
*Price per user. Quantity must be 250 or greater
#BNDPF3
Our Price: $97.75
NCP Dynamic Net Guard Client (Windows 32/64 Bit), 500 to 1499 users
*Price per user. Quantity must be 500 or greater
#BNDPF4
Our Price: $92.00

More pricing below, click here!

Overview:

NCP's Net Guard Board

NCP’s Dynamic reliably protects end-devices from unauthorized access and offers a wide range of features which allow for easy handling and administration. Location awareness through Friendly Net Detection, strong authentication with certificates, immediate protection of the end-device from system startup onwards and the Silent Mode are just some of these features.

Key features:

  • Location awareness through Friendly Net Detection for dynamic adaptation of firewall rules
  • Tightly sealed security gaps through “Silent Mode” and immediately active firewall software as early as system startup
  • Transparency for administrators and efficient operation through “Single Point of Administration”

Features and Benefits:

Scope of Supply and Features

NCP's Net Guard (Win32/64) complements NCP's "Next Generation Network Access Technology"- the holistic Secure Communications Solution. It protects laptops, notebooks, netbooks, tablet PCs and desktop PCs with Windows 32/64 Bit operating systems - Windows 7, Windows Vista, Windows XP – from unauthorized access. The end-device is always protected against attacks, be it mobile or stationary, be it on the internet, in a Wi-Fi network or in a LAN.

Depending on the location different firewall rules apply. For example, firewall rules for a public hotspot differ from firewall rules for the home office or for the corporate Wi-Fi network or LAN. On the one hand, the Net Guard offers full protection of the PC on the highest possible security level, while on the other hand it allows for a defined openness for adminis-tration purposes, for example.

The firewall software immediately recognizes "secure" and "insecure" networks: Depending on the environment, "Friendly Net Detection" (FND) activates the respective firewall rules. In comparison to common firewall solutions, the major advantage is that a FND server, which is installed within the corporate network, authenticates itself towards the Net Guard Client (Local Awareness) and thus ensures recognition of a friendly network at any rate.

Various firewall rules may be created for ports, IP addresses, segments or applications. Furthermore it is possible to define whether internet access is allowed (generally or for selected websites only) and/ or whether the corporate network may be accessed exclusively. It is possible for the administrator to lock all client settings so that the user may not alter any of them. This excludes deliberate manipulation or misconfiguration by the user.

Since the NCP firewall is immediately active at system startup of the mobile or stationary end-device, this severe security gap is tightly sealed.

The "Silent Mode" prevents the user from being constantly interrupted by software prompts. This default mode eliminates the most frequent source for errors – the users' frequent and doubtful confirmation of firewall prompts.

Use the Net Guard in a local network and as remote access application in connection with various VPN technologies.

Centrally Managed Personal Firewall for Secure Network Access
Centrally Managed Personal Firewall for Secure Network Access

Central Administration

Central administration is carried out via the established NCP Secure Enterprise Management. As "Single Point of Administra-tion, the NCP Secure Enterprise Management features all functions and automatisms necessary for rollout, implementa-tion and efficient operation. All firewall settings may be defined for every single user in particular.

NCP Net Guard offers increased security for the terminal device, and optimized features specifically designed for use in remote access applications. These are activated when the NCP Internet Connectors is used to establish a connection.

Technical Data:

Net Guard: Technical Data
Operating Systems Microsoft Windows (32 and 64 bit): Windows 8, Windows 7, Windows Vista
Security Features Stateful Packet Inspection, application dependent firewall rules;
Friendly Net Detection (evaluation of: current network address, IP address and MAC address of the DHCP server);
Secure Hotspot Logon;
Different firewall rules for: protocols, ports and addresses
Central Management NCP Secure Enterprise Management
Configuration Parameter
  • Application and connection dependent filter rules
  • Protocol, port- and address dependent filter rules
  • Definition of friendly network recognition (the network's IP address, network mask, IP address of the DHCP server, MAC address)
  • Logging settings
  • Central definition of the user's access possibilities to the firewall configuration
  • Friendly Net Detection (FND) server configuration
Technical Data NCP Internet Connectors (Dialer)
Operating Systems Microsoft Windows (32 and 64 bit): Windows 8, Windows 7, Windows Vista
Transmission Media Internet, analog telephone network, xDSL, LAN, WiFi, 3G
Authentication Processes AP, CHAP, MS CHAP V.2;
IEEE 802.1x: EAP-MD5 (Extensible Authentication Protocol): Extended authentication relative to switches and access points (Layer 2);
EAP-TLS (Extensible Authentication Protocol - Transport Layer Security): Extended authentication relative to switches and access points on the basis of certificates (Layer 2);
Support of certificates in a PKI: Soft certificates, smart cards, and USB tokens
Budget Manager Administration of connection times and/or volumes for GPRS/UMTS and WLAN; separate administration processes for international roaming with 3G
Automatic Media Recognition Automatic recognition and graphic display of all available connection types; selection of the fastest available transmission medium. Search routine prioritization: LAN, WiFi, DSL, 3G, Modem
IP Address Allocation DHCP (Dynamic Host Control Protocol)
Line Management Short Hold Mode
Point-to-Point Protocols PPP over GSM, PPP over PSTN, PPP over Ethernet, LCP, IPCP, MLP, CCP, PAP, CHAP, ECP
Client Monitor
Intuitive, Graphical User Interface
MonitorMultilingual (English, German, French); configuration, connection management and monitoring, connection statistics, log-files, trace tool for error diagnosis; traffic light icon for display of connection status; integrated support of Mobile Connect Cards (PCMCIA, embedded); password protected configuration management and profile management, configuration parameter lock

*) Prerequisite: NCP Secure Enterprise Management

Documentation:

Download the NCP Net Guard Datasheet (PDF).

Pricing notes:

NCP Products
NCP Managed Dynamic Net Guard
NCP Dynamic Net Guard Client (Windows 32/64 Bit), 1 to 99 users
*Price per user. Quantity must be 1 or greater
#BNDPF1
Our Price: $126.50
NCP Dynamic Net Guard Client (Windows 32/64 Bit), 100 to 249 users
*Price per user. Quantity must be 100 or greater
#BNDPF2
Our Price: $109.25
NCP Dynamic Net Guard Client (Windows 32/64 Bit), 250 to 499 users
*Price per user. Quantity must be 250 or greater
#BNDPF3
Our Price: $97.75
NCP Dynamic Net Guard Client (Windows 32/64 Bit), 500 to 1499 users
*Price per user. Quantity must be 500 or greater
#BNDPF4
Our Price: $92.00
NCP Dynamic Net Guard Client (Windows 32/64 Bit), 1500 to 1999 users
*Price per user. Quantity must be 500 or greater
#BNDPF5
Our Price: $86.25
NCP Managed Dynamic Net Guard Update
NCP Dynamic Net Guard Client (Windows 32/64 Bit), Update 1 Version
#UBNDPF135
Our Price: $44.28
NCP Dynamic Net Guard Client (Windows 32/64 Bit), Update 2 Versions
#UBNDPF150
Our Price: $63.25
